Wide Band Gap Semiconductor Nanowires for Optical Devices 1


Low-Dimensionality Related Effects and Growth

Wide Band Gap Semiconductor Nanowires for Optical Devices 1

Edited by

Vincent Consonni, INP-CNRS, Grenoble, France
Guy Feuillet, CEA-LETI, Grenoble, France


ISBN : 9781848215979

Publication Date : July 2014

Hardcover 400 pp

170.00 USD

Co-publisher

Description


Over the last ten years, GaN and ZnO nanowires have emerged as potential building blocks for the next generation of optoelectronic devices including LEDs, lasers, UV photodetectors and solar cells. This has led to an increasing number of publications in the field, which now outnumbers 10,000. In view of this wealth of information, this two-volume series is intended to give a detailed status of the research topic dedicated to GaN and ZnO nanowires. In particular, dealing with these two different but closely related semiconductors yields valuable comparisons and benefits the general understanding of this subject, helping promote the development of related optoelectronic applications.

The comprehensive books gather review articles written by pioneering and world-leading scientists at the forefront of basic and applied research, covering all aspects from low-dimensionality effects to optoelectronic devices through to nanowire growth and their related heterostructures.
This first volume centers on the physical properties of GaN and ZnO nanowires that are specifically related to low-dimensionality effects. It also focuses on their nucleation and growth mechanisms by different physical vapor and chemical deposition techniques. This first volume serves as a toolbox for designing and fabricating nanowire heterostructures for dedicated optoelectronic devices, as detailed in the second volume.

This book is of interest not only to physicists, chemists or materials scientists interested in the topic of one-dimensional nanostructures and their optoelectronic applications, but also to semiconductor scientists already in the field but looking for an extended overview.

Contents


Part 1. GaN AND ZnO Nanowires: Low-Dimensionality Effects
1. Quantum and Optical Confinement, Le Si Dang.
2. Stress Relaxation in Nanowires with Heterostructures, Frank Glas.
3. Surface-Related Optical Properties of GaN-Based Nanowires, Pierre Lefebvre.
4. Surface Related Optical Properties of ZnO Nanowires, Tobias Voss and Jürgen Gutowski.
5. Doping and Transport, Julien Pernot, Fabrice Donatini and Pierre Tchoulfian.
6. Microstructure of Group III-N Nanowires, Achim Trampert, Xiang Kong, Esperanza Luna, Javier Grandal and Bernd Jenichen.
Part 2. Nucleation and Growth Mechanisms of GaN and ZnO Nanowires
7. Ni Collector-Induced Growth of GaN Nanowires on C-Plane Sapphire by Plasma-Assisted Molecular Beam Epitaxy, Caroline Chèze.
8. Self-Induced Growth of GaN Nanowires by Molecular Beam Epitaxy, Vincent Consonni.
9. Selective Area Growth of GaN Nanowires by Plasma-Assisted Molecular Beam Epitaxy, Miguel A. Sanchez-Garcia, Steven Albert, Ana M. Bengoechea-Encabo, Francesca Barbagini and Enrique Calleja.
10. Metal-Organic Vapor Phase Epitaxy Growth of GaN Nanorods, Joël Eymery.
11. Metal-Organic Chemical Vapor Deposition Growth of ZnO Nanowires, Vincent Sallet.
12. Pulsed-Laser Deposition of ZnO Nanowires, Christoph Peter Dietrich and Marius Grundmann.
13. Preparation of ZnO Nanorods and Nanowires by Wet Chemistry, Thierry Pauporté.

About the authors/editors


Vincent Consonni is Associate Research Scientist at CNRS (French Center for National Research) in France. His research has focused on the chemistry and physics of crystal growth and of condensed matter for micro- and nanostructures involving GaN and ZnO nanowires.
Guy Feuillet is Senior Research Scientist at CEA (French Atomic and Alternative Energy Commission) in France. He has initiated and coordinated many internal R&D programs (GaN and ZnO nanostructures, X-ray detection, solid state lighting) during his work at CEA. He is a permanent member of the scientific advisory board at CEA/LETI.
